| Frame |
CF5 V carbon - Premium fibres for lightweight and performance, race geometry. Internal cable routing, 142 x12mm axle standard, flat mount rear brakes with Disc Cooler, 1 1/2" to 1 1/4" headtube. Pressfit 86.5 BB Standard, Max tyre size - 30c
|
| Fork |
Scultura CF5 Disc; full carbon; Max tyre size: 700 x 30c - Disc cooler technology
|
| Gears |
24 |
| Shifters |
SRAM RED AXS
|
| Front Derailleur |
SRAM RED AXS |
| Rear Derailleur |
SRAM RED AXS |
| Bottom Bracket |
BB DUB PF ROAD; 86.5 |
| Chain |
Sram Red E1 |
| Chainset |
SRAM RED AXS; 50-37 tooth chainset; Power Meter; Crank length - 165mm (XXS), 170mm (XS), 172.5mm (S/M/L), 175mm (XL) |
| Cassette |
SRAM CS XG 1290 E1; 10-36 teeth; 12 speed |
| Brake Lever |
SRAM RED AXS |
| Front Brake |
SRAM RED AXS; Hydraulic disc brake caliper with SRAM DB Paceline X Centrelock; 160mm rotor |
| Rear Brake |
SRAM RED AXS; Hydraulic disc brake caliper with SRAM DB Paceline X Centrelock; 160mm rotor |
| Grip |
Merida Expert
|
| Handlebar |
Team SL 1P Integrated; carbon; 380mm (XXS-XS-S), 400mm (M-L-XL) |
| Stem |
Team One-Piece Integrated; carbon - Length - 90mm (XXS-XS), 100mm (S), 110mm (M-L), 120mm (XL) |
| Headset |
Merida Team SL (OP-203 neck) |
| Pedal |
Not Included |
| Saddle |
Prologo Scratch M5 with V-mount adapter; includes Merida minitool |
| Seatpost |
Merida Team SL; 27.2mm diameter; 15mm layback; Carbon; S-Flex |
| Wheel Size |
700C |
| Rims |
Part of wheelset -Zipp WH-353-NSW Tubeless; 25mm inner rim width; Carbon |
| Spokes |
Part of wheelset |
| Front Hub |
Part of wheelset - Zipp WH-353-NSW Tubeless; 100 x 12mm; Centerlock |
| Rear Hub |
Part of wheelset - Zipp WH-353-NSW Tubeless; 142 x 12mm; Centerlock; Sram xdr |
| Front Tyre |
Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead; tubeless ready |
| Rear Tyre |
Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead; tubeless ready |
